Additional information can be found on the VAM Services website or the VAM. Running Book. c. Drift. The drift is the guaranteed internal diameter of both pipe. BOOK 18February Introduction Congratulations on selecting pipe threaded with VAM connections. VAM connections were first developed in the early. The Hours of Louis XII was one of the greatest French illuminated manuscripts of the Renaissance. A prayer book, it was decorated by Jean Bourdichon for the.
After manufacture the pipe will state 'D' on the stencilling to show that the standard API drift was used, 'DA xxxx' will be stencilled to show that an alternate drift was used 24 th August 21 2 Pipe Preparation and Running Equipment 2 Pipe Preparation and Running Equipment with xxxx being the drift size.
DT42 is used on the stencil to indicate that a 42" long drift was used for casing sizes.
This is only applied when casing is used as tubing. There are 3 very common pipe sizes where alternate drifts are commonly used. These are listed below. If casing is used for tubing application then the drift used should be 42" long. Do not drift GRE lined pipe at the rig site as the drift mandrel may detach the flare at the pipe end. In the case of GRE lined pipe the supply chain from the company inserting the lining to the rig site must be robust.
The length written on the pipe and pup joints coming from the manufacturer is the overall length of the part. This is seldom accurate enough for an oil company so most manufactures try to be more accurate. It is vital that an 22 24 th August accurate measurement is made in case the manufactures length is not accurate enough or in case of recuts.
When running threaded connections the effective length is less as the box thread 'swallows' the pin thread. This is known as the make-up loss. The make-up loss is different for different sizes, weights and connections so it is important that this is known for each connection type.
The make-up loss must be subtracted from the overall length to give the effective length as shown on the picture below. It is best to look up the make-up loss in this book or by using the connection data sheet on the VAM Services website.
Do not measure the make-up loss using a metal rule as it may score the seal area. To measure the pipe length either a metal 'tally tape' or a laser can be used. In either case make sure that the datum point of each does not damage the pin seals.
When marking the tally length and number on CRA pipe use paints that do not contain halogens. Halogens cover the following elements: fluorine, F ; chlorine, Cl ; bromine, Br ; iodine, I ; and astatine At. This means Trichloroethylene which is sometimes found in paints or paint stick markers must be avoided.
Take care not to apply tally numbers or lengths over the original pipe markings as identification and traceability may be lost. If running is about to start then it may not be necessary to refit the box protector.
For special clearance or integral that could be damaged during transportation the box protector is required. There follows below a list then details of the minimum equipment that is required.
The reason for this is that if a connection has to be backed out the torque may be higher than make-up torque. The grips must be adjusted so that they hold the pipe firmly and not slip. Equally the pressure must not be too high or the pipe body can be damaged. For pipe sizes of 7" and below it is recommended to use a tong with integrated back-up jaws.
On larger sizes it is acceptable to use a tong with a snub line. The tong must have the facility to lower gradually as the threads are made-up. When positioned over the pipe the tong must hang horizontally and not as shown below. When using a tong with integral back-up, one set of jaws must be 'free floating' to compensate for any end kink or bend in the pipe or misalignment between the tong jaws.
There must be sufficient travel between the tong and 24 th August 25 2 Pipe Preparation and Running Equipment 2 Pipe Preparation and Running Equipment back-up to compensate for the make-up loss as the threads are engaged.
When positioned over the pipe the tong must hang horizontally with the tong and back-up tong being parallel. On some rigs the tong operation is done remotely. The tong may be mounted on an extending hydraulic arm or on a frame that is pushed over the pipe as required.
Frequently bought together
Pipe wrenches, rig tongs or spinning chain make-up are not permitted. In recent years companies have applied torque using a top drive make-up system.
This tool provides three functions. To reduce the chance of damage to the upper box connection or of debris being left on the torque shoulder an open end protector or handling plug is recommended to be fitted. It is also important that there is good alignment between the top drive makeup system and the rotary table as the pipe is fixed at both ends. If using a top drive make-up system in conjunction with a standard tong care must be taken to ensure that when running connections requiring a handling 26 24 th August plug that the plug does not unscrew as the pipe is made-up.
In all other cases the connection must be made-up to the correct torque value and the torque increase to this value must be within the correct parameters. In the past or with DINO VAM it was sufficient to use only a dial gauge to check this build up in torque and it was the skill of the tong operator to determined if the make-up was within parameters.
With new technology, more complex connections, and more demanding performances it is strongly recommended that the torque is plotted on a graph and that a record of this plot is kept. The graph can be produced on paper but is now more likely to be displayed on a computer screen. Different connections have a different graph profile and this is known as the signature of the connection. The machining tolerances of the connections, the thread compound and other factors can affect this signature.
The signature is produced by displaying torque on the vertical axis and turns on the horizontal axis.
Both axis must have a linear scale. Only the last 2 to 3 turns require to be shown as the torque increases to the final make-up. Often turns are substituted by time on the horizontal axis but this does not give such a true signature and is not recommended. To measure torque a load cell is required. The load cell can be either, hydraulic and connected to a dial gauge, or it can be electronic and connected to a computer.
As the gauge and computer displays torque and not load the value is multiplied by the arm length to give a value of torque. To confirm the accuracy of the load cell it can be compared to that of a second load cell with known calibration on a snub line.
The equipment must be calibrated at a sufficient frequency across its working range. The turns counter must be capable of recording a minimum of positions per turn. In all cases the company supplying the make-up equipment must be able to 24 th August 27 2 Pipe Preparation and Running Equipment 2 Pipe Preparation and Running Equipment supply a calibration certificate to the user.
This certificate must show that the equipment has been calibrated to National Standards within the previous 6 months.
If using a computer to display torque verses turns the make-up graph produced should have the following features. The screen resolution must be at least x pixels. This is sometimes known as shadowing. By doing this any unusual profiles can be easily identified and questioned. To do this the make-up graphs must have the shoulder point or the final torque plotted on the same datum line on the turns axis.
Shadow graphs with final torque as the datum 28 24 th August Shadow graphs with shoulder torque as the datum with minimum and maximum delta turns shown An alternative idea is to plot an average graph for the job and display high and low lines. Any graphs out with the high and low lines will be highlighted as different and be cause for alarm. It is also recommended to have a speed verses turns display either on the make-up graph or as a separate graph.
It is not acceptable for computer software to report a make-up as acceptable without validation by a competent person. This is normally done by dragging the pipe from the box end along a catwalk and up an inclined slope called the Vee door.
The pipe can be lifted to the vertical position by attaching a single joint elevator behind the coupling or a handling plug for integral connections and using a tugger line 24 th August 29 2 Pipe Preparation and Running Equipment 2 Pipe Preparation and Running Equipment to pull the pipe up. The single joint elevators must fit neatly round the pipe and have a safety pin to ensure they do not accidently unlatch. It is always necessary to use a pin protector and depending on how much impact there is with the Vee door a box protector may also be required.
If running integral connections with increased pipe OD dimensions then special single joint elevators are required to allow for the larger diameter at the connection. Alternative methods exist to pick up the pipe including 'pick-up and lay down machines' which replace catwalks and raise the pipe on a conveyor system where it can be latched directly by the main elevators. Another method is a pipe handling system which consists of a grab arm which takes the pipe from the catwalk and lifts it to the vertical position before swinging it into the drill floor and to the stabbing position.
It is normally possible to handle the pipe without protectors as long as the connections are not damaged by this handling method. The jaws must be clean and sharp.
Slip type elevators are recommended for integral connections, special clearance couplings, special bevel couplings and fatigue enhanced connections. If using side door elevators for integral strings then lifting subs are required. The amount of load that can be lifted on the coupling face for all threaded and coupled connections using side door elevators is limited.
The reason for this is that the cross sectional area of the coupling face is normally much less than the critical cross sectional area of the connection. If the string weight will exceed this value then the pipe must be gripped on the pipe body and not the coupling face. To do this slip type elevators are required.
Remember if the coupling has a special clearance or a bevel this value will be much less so make sure to look up the coupling face cross section for the correct coupling design option. They can be manually inserted or operated remotely. They can be mounted on the rotary table or flush with the drill floor.
Slips work best when the string weight is high. For the first few joints it may be necessary to compliment the slips by inserting a safety clamp round the pipe. This will reduce the chance of the string falling into the well if the slips fail.
Slips must be designed with jaws that wrap around as much of the pipe body as possible. For chromium steels the jaws must be non ferrous and low marking.
On carbon steels the jaw marks must be less than indicated below. A pit depth gauge is required to measure the depth of jaw mark.
After this point the connections will never be seen so great care must be taken to ensure that no damage occurs during stabbing. The best method to protect against stabbing damage is to use a stabbing guide. This is a plastic guide which is fitted over the box connection in the rotary table. As the pin is inserted into the box the guide will ensure it is central and prevent damage to the connections.
