𝗣𝗗𝗙 | A new application of IR sensors for the detection of game is presented. The device detects wildlife (mammals, birds) by using the. The IR sensor module consists mainly of the IR Transmitter and Receiver, Opamp , Variable Resistor (Trimmer pot), output LED in brief. IR sensor circuit is used to detect the presence of IR signals from electronic device. Get idea on Infrared detector circuit diagram and working principle.

Moisture Analyzers Moisture analyzers use wavelengths which are absorbed by the moisture in the IR region. Objects are irradiated with light having these wavelengths 1.

Infrared IR Sensor Circuit Diagram and Working Principle

The Lights reflected from the objects depend upon the moisture content and is detected by analyzer to measure moisture ratio of reflected light at these wavelengths to the reflected light at reference wavelength. Gas Analyzers IR sensors are used in gas analyzers which use absorption characteristics of gases in the IR region. Two types of methods are used to measure the density of gas such as dispersive and non dispersive.

Gas Analizer Dispersive: An Emitted light is spectroscopically divided and their absorption characteristics are used to analyze the gas ingredients and the sample quantity.

Non dispersive: It is most commonly used method and it uses absorption characteristics without dividing the emitted light. Non dispersive types use discrete optical band pass filters, similar to sunglasses that are used for eye protection to filter out unwanted UV radiation.

This type of configuration is commonly referred to as non dispersive infrared NDIR technology. This type of analyzer is used for carbonated drinks, whereas non dispersive analyzer is used in most of the commercial IR instruments, for an automobile exhaust gas fuel leakages.

IR Imaging Devices IR image device is one of the major applications of IR waves, primarily by virtue of its property that is not visible. It is used for thermal imagers, night vision devices, etc. Thermal imagers usually composed of a Sb indium antimonite , Gd Hg mercury-doped germanium , Hg Cd Te mercury-cadmium-telluride sensors. Then the Cooling the detectors ensures that the radiant energy photons recorded by the detectors comes from the terrain and not from the ambient temperature of objects within the scanner itself an IR imaging electronic devices.

Thus, this is all about IR sensor circuit with working and applications. These sensors are used in many sensor based electronics projects. We believe that, you might have got a better understanding of this IR sensor and its working principle. Furthermore, any doubts regarding this article or projects please give your feedback by commenting in the comment section below. Intrinsic type quantum detectors are photoconductive cells and photovoltaic cells.

Active infrared sensors consist of two elements: infrared source and infrared detector. Infrared sources include an LED or infrared laser diode.

Navigation menu

Infrared detectors include photodiodes or phototransistors. The energy emitted by the infrared source is reflected by an object and falls on the infrared detector. The picture of a typical Infrared LED is shown below. There are different types of infrared transmitters depending on their wavelengths, output power and response time. A simple infrared transmitter can be constructed using an infrared LED, a current limiting resistor and a power supply. The schematic of a typical IR transmitter is shown below.

When operated at a supply of 5V, the IR transmitter consumes about 3 to 5 mA of current. Infrared transmitters can be modulated to produce a particular frequency of infrared light. IR transmitters can be found in several applications. Some applications require infrared heat and the best infrared source is infrared transmitter. When infrared emitters are used with Quartz, solar cells can be made. IR receivers come in the form of photodiodes and phototransistors.

Infrared Photodiodes are different from normal photo diodes as they detect only infrared radiation. The picture of a typical IR receiver or a photodiode is shown below. Different types of IR receivers exist based on the wavelength, voltage, package, etc. When used in an infrared transmitter — receiver combination, the wavelength of the receiver should match with that of the transmitter.

A typical infrared receiver circuit using a phototransistor is shown below. This in turn lights up the LED which acts as a load. The potentiometer is used to control the sensitivity of the phototransistor.

When the IR transmitter emits radiation, it reaches the object and some of the radiation reflects back to the IR receiver. Based on the intensity of the reception by the IR receiver, the output of the sensor is defined. IR LED emits infrared light. The Photodiode detects the infrared light. An IC Op — Amp is used as a voltage comparator. The potentiometer is used to calibrate the output of the sensor according to the requirement.

When the light emitted by the IR LED is incident on the photodiode after hitting an object, the resistance of the photodiode falls down from a huge value.

One of the input of the op — amp is at threshold value set by the potentiometer. When the incident radiation is more on the photodiode, the voltage drop across the series resistor will be high.

infrared sensor download importers

In the IC, both the threshold voltage and the voltage across the series resistor are compared. If the voltage across the resistor series to photodiode is greater than that of the threshold voltage, the output of the IC Op — Amp is high. The threshold voltage can be adjusted by adjusting the potentiometer depending on the environmental conditions.

Hence there is a line of sight communication between the infrared transmitter and the receiver.

Infrared IR Sensor Circuit Diagram and Working Principle

If an object falls in this line, it obstructs the radiation from reaching the receiver either by reflecting the radiation or absorbing the radiation.The wavelengths of these regions and their applications are shown below. When infrared emitters are used with Quartz, solar cells can be made. Thermal infrared sensors use infrared energy as the source of heat and are independent of wavelength.

These sensors are used in many sensor based electronics projects. Photodiode is a semiconductor which has a P-N junction, operated in Reverse Bias, means it start conducting the current in reverse direction when Light falls on it, and the amount of current flow is proportional to the amount of Light.
