Amplitude shift keying - ASK - in the context of digital communications is a modulation process which imparts to a sinusoid two or more discrete amplitude. Amplitude Shift Keying (ASK) is the digital modulation technique. To plot the wave form for Binary Frequency Shift Keying (BFSK) signal using MATLAB. 4 Phase Shift Keying. Frequency Shift Keying Modulation. Equipment used: • Oscilloscope Theory Amplitude shift keying - ASK - in the context of digital.
When the carrier wave is C t and the modulating signal is m t , the modulated wave Sam is as follows. In the case of a digital signal, the modulating signal applied to the modulator is called digital modulation.
The modulator is the same as for analog modulation. With OOK, the amplitude direction of the modulated wave is indicated by the presence or absence of a carrier wave. In other words, when the signal is 0, there is no carrier wave and when it is 1, there is a carrier wave.
The spectrum of the ASK modulated wave is centered on the carrier frequency and the square wave spectrum which is the modulating signal takes a spread-out form. Expressed as a formula, carrier wave C t takes the following form.
Amplitude-shift keying ASK is a form of amplitude modulation that represents digital data as variations in the amplitude of a carrier wave. In an ASK system, the binary symbol 1 is represented by transmitting a fixed-amplitude carrier wave and fixed frequency for a bit duration of T seconds. If the signal value is 1 then the carrier signal will be transmitted; otherwise, a signal value of 0 will be transmitted.
Amplitude Shift Keying & Frequency Shift Keying
Any digital modulation scheme uses a finite number of distinct signals to represent digital data. ASK uses a finite number of amplitudes, each assigned a unique pattern of binary digits.
Usually, each amplitude encodes an equal number of bits. Each pattern of bits forms the symbol that is represented by the particular amplitude.
The demodulator , which is designed specifically for the symbol-set used by the modulator, determines the amplitude of the received signal and maps it back to the symbol it represents, thus recovering the original data.
Frequency and phase of the carrier are kept constant.
Both ASK modulation and demodulation processes are relatively inexpensive. The ASK technique is also commonly used to transmit digital data over optical fiber. For LED transmitters, binary 1 is represented by a short pulse of light and binary 0 by the absence of light.
Laser transmitters normally have a fixed "bias" current that causes the device to emit a low light level. This low level represents binary 0, while a higher-amplitude lightwave represents binary 1.
The simplest and most common form of ASK operates as a switch, using the presence of a carrier wave to indicate a binary one and its absence to indicate a binary zero. This type of modulation is called on-off keying OOK , and is used at radio frequencies to transmit Morse code referred to as continuous wave operation ,.
Amplitude Shift Keying
Figure 1: an ASK signal below and the message above There are sharp discontinuities shown at the transition points. These result in the signal having an unnecessarily wide bandwidth.
The bandlimiting may be applied to the digital message, or the modulated signal itself. The data rate is often made a sub-multiple of the carrier frequency. This has been done in the waveform of Figure 1.
This makes its processing eg, power amplification more difficult, since linearity becomes an important factor. However, it does make for ease of demodulation with an envelope detector. Figure 2: the two stages of the demodulation process It is apparent from Figures 1 and 2 that the ASK signal has a well defined envelope.
Thus it is amenable to demodulation by an envelope detector. With bandlimiting of the transmitted ASK neither of these demodulation methods envelope detection or synchronous demodulation would recover the original binary sequence; instead, their outputs would be a bandlimited version. Thus further processing - by some sort of decision-making circuitry for example - would be necessary.
Thus demodulation is a two-stage process: 1. In addition, note the effect of the communication channel on the ASK signal. As the communication channel is limited band the frequency response if low pass , the ASK output signal is slightly beveled.
The effect is the more evident if a Hz carrier is used switch SW4. Take SW4 to the position again TP Q3 Why is the ASK much sensible to signal amplitude variations?
Which is the reason why?There is a determinate phase symbol for each pair of bits. This has been done in the waveform of Figure 1.
Hence the signal constellation consists of the signal- space 4 points. Skip to main content. In an ASK system, the binary symbol 1 is represented by transmitting a fixed-amplitude carrier wave and fixed frequency for a bit duration of T seconds.
Different symbols are represented with different voltages.
